Brand Name : | DREAM-START |
Model Number : | DR-D18 |
Supply Ability : | 100000 Piece/Pieces per Month M12 connector |
Price : | $0.54 - $1/pieces |
Certification : | TUV |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Delivery Time : | Within 24 hours |
1. M12 metal nut type docking assembly, more exquisite and more durable;
2. Integrating current and signal transmission in one of the
multi-functional comprehensive waterproof plug;
3. Metal nut locking makes a better tensile performance and better
waterproof performance;
4. The male and female pins of gold-plated ensure the conducting
performance's stability, safe and reliable;
5. Mainly used for upscale lighting accessories lines and other
upscale products.
Pins Number | Rated Current | Rated Voltage | Contact Resistance | Contact Resistance | IP-Code | Cable Specifications | Cable Range |
2 | 8A | 110V AC | 10mΩ | 200MΩ | IP67 | ≤1.0mm2 | 0-7.5mm |
3 | 8A | 110V AC | 10mΩ | 200MΩ | IP67 | ≤1.0mm2 | 0-7.5mm |
4 | 5A | 80V AC | 10mΩ | 200MΩ | IP67 | ≤0.75mm2 | 0-7.5mm |
5 | 5A | 80V AC | 10mΩ | 200MΩ | IP67 | ≤0.5mm2 | 0-7.5mm |
6 | 4A | 60V AC | 10mΩ | 200MΩ | IP67 | ≤0.5mm2 | 0-7.5mm |
![]() |
