    Round 7-Pin Twist-Lock Photocontrol

    Ask Lasest Price
    Brand Name : DREAM-START
    Model Number : DR-E03
    Certification : UL/TUV/ROHS/CE
    Price : $1.2-1.55/pieces 10-500pieces
    Payment Terms : Western Union, MoneyGram, D/P, T/T, D/A, L/C
    Supply Ability : 50000 Piece/Pieces per Month
    Delivery Time : 1-10 work days
    • Product Details
    • Company Profile

    Round 7-Pin Twist-Lock Photocontrol

    I

    NEMA socket provides an electrical and mechanical connection between the control cell and the luminaire.

    ANSI C136 coded standard clearly defines the size of the socket, the type of locking and other details.

    NEMA socket is a standardized type of connection across the lighting industry.


    NEMA socket has demountable structure. Therefore, this makes it easier to do things like installation,

    maintenance and repair. NEMA socket provides a reliable power connection with strong twist lock contacts.


    Basic Specification:

    DR-E03 (Photocontrol) Parameters

    Sensor Type
    Photodiode
    Rated Voltage
    110V~240V AC
    Wide Input Voltage Range
    100V~277Vac
    Working Mode
    <10~20 Lux / ON , >30~60Lux / OFF,Time-delay: 2 Seconds
    Load Current
    15A (220Vac)
    Ambient Temp
    -40℃~105℃
    Size
    φ80.5mm * φ51.6mm(Height)
    Case Material
    UV resistant PC
    Shell Design
    It Conforms to American National Standard ANSI C136.41-2013
    Safety Certification
    E510435,Vol 1 , Contact Us For More Informations
    Life Span
    Quality Assurance for 3 Years
    Applications
    Street /Roadway Lighting, Photocontrol Lighting, Parking Lot Lighting,
    Garden Lighting, Smart City, Smart Street Light, 5G, Smart Pole

    Packing & Delivery



    Quality Round 7-Pin Twist-Lock Photocontrol for sale
